HISTORY

produced for develop the chined hull surface of a sailing boat. (stitch and glue construction)

developing the surface formed by two curves, in case the chines of the hull.

considers bow and stern vertical lines!

text about surface development - Working With Developable Surfaces

Download files

source for eclipse

library uses gnu gsl (gnu scientific library)

see usage example (by google translator)

USE OF ZigZag

./zigzag [kind of interp.] [intervals] [curveA_3d] [curveB_3d]

kind of interp - AA - akima akima

LL - linear linear

AL - akima linear

LA - linear akima

intervals - the number of elements in the mesh. ( better value near 500 in my test )

curveA - 3d file of points of the curve A.

curveB - curve B.

recommend using the largest dimension of the plate as x.

Always start and end with the same x curves.

obs: see more about interpolation on gsl documentation

FORMAT OF CURVES: (dimensionless values)

X Y Z

Result: 2 rows of flattened surface with ends connected by straight!

curvaA.txt

curvaB.txt

Limitations:

Excludes stretch.

Consider the surface formed by a line that runs vertically through the two curves,

That seems to be enough in a hull chined with little deformation.
